| Model |
F18 Pro |
| Display |
2.4″ @ TFT Color LCD Screen (720 × 1280) |
| Camera |
4MP CMOS |
| Operation System |
Linux |
| Hardware |
CPU: 1GHz Dual Core
RAM: 128MB; ROM: 256MB
Speaker ×2 8Ω 1W
Microphone ×1 (Sensitivity: 42dB ±3dB)
Fingerprint Sensor: ZK Optical Sensor
TF Card: Max 256GB |
| Authentication Method |
Fingerprint / Card / Password (Physical Keypad) |
| Fingerprint Template Capacity |
3,000 (1:N) |
| Card Capacity |
5,000 (1:N) |
| User Capacity |
5,000 (1:N) |
| Transaction Capacity |
100,000 |
| Max. User Password Length |
6 to 8 Digits |
| Biometric Verification Speed |
Less than 0.3 sec (Fingerprint) |
| False Acceptance Rate (FAR) |
≤ 0.0001% |
| False Rejection Rate (FRR) |
≤ 0.01% |
| Biometrics Algorithm |
ZKFingerprint V10.0 / V13.0 (Default) |
| Card Type |
ID & IC Card @ 125kHz & 13.56MHz (Standard) |
| Communication |
TCP/IP ×1
Wi-Fi (IEEE 802.11 b/g/n) @ 2.4GHz
Wiegand (Input & Output) ×1
RS485: ZKTeco RS485 ×1
RS232: Printer Only (Optional)
USB Host ×1
Aux Inputs ×1
Electric Lock ×1
Door Sensor ×1
Exit Button ×1
Alarm ×1
Doorbell ×1 |
| Standard Functions |
ADMS
DST
Up to 14-digit User ID
Access Levels
Groups
Holidays
Anti-Passback
Record Query
Tamper Switch Alarm
Multiple Verification Methods
Video Intercom (Yoosee)
AC PUSH & TA PUSH Protocol Switch
HTTPS / SSH Backend Access
T9 Keyboard (Input) |
| Video Intercom |
Supports Yoosee Mobile App (300 devices, share up to 10 users/device). Live View (10 mins/session), Two-way Audio, Remote Unlock. |
| Cloud Service |
Gwell Cloud for Video Storage & Video Analytics |
| Video Storage |
Gwell Cloud Service |
| Video Compression |
H.265, 15fps |
| Visible Range |
Up to 5m (Day & Night, Infrared) |
| Video Resolution |
2560 × 1440 |
| Video Viewing Angle |
154.8° (Diagonal), 77.6° (Vertical), 134.7° (Horizontal) |
| Infrared Supplement Light |
Auto ON: < 2 lux (B/W Image)
Auto OFF: > 6 lux
Visible Light Mode: ≥ 6 lux (Color Image) |
| IVA Camera |
Person Detection, Motion Detection, Vehicle Detection, Flame Detection |
| IVA Video |
Intelligent Retrieval, Live View, Playback & Backup (Cloud / TF Card up to 256GB) |
| IVA Alarm |
Person / Motion / Vehicle / Flame Detection |
| Alarm Delay |
Less than 3 sec |
| Minimum Detection Area |
50 × 50 Pixels |
| Sensitivity Adjustable |
N/A |
| Networking & Interfaces |
Wireless: Dual-band WiFi 6 (802.11 a/b/g/n/ac/ax), 2.4/5GHz
Ethernet ×1
Bluetooth 5.0 |
| Power Supply |
DC 12V 3A |
| Operating Temperature |
-10℃ to 45℃ (14℉ to 113℉) |
| Operating Humidity |
10% to 90% RH (Non-condensing) |
| Dimensions |
214 × 80 × 45 mm |
| Gross Weight |
0.75 Kg |
| Net Weight |
0.38 Kg |
| Supported Software |
Software: ZKBio CVAccess / ZKBio Time
Mobile App: Yoosee
Cloud Storage: Gwell |
| Installation |
Wall Mount (Compatible with Asian, Single & European Gang Boxes) |
| Housing Material |
ABS (Black) |
| Ingress Protection Rating |
N/A |
| Certifications |
ISO14001, ISO9001, CE, FCC, Equivalent to RoHS |
| Factory ID |
AC01-F28H-12 |
